Broadcast converter

Product Highlights

• Convert SD & HD Formats
• Hot-Swappable Card for OpenGear Frame
• Converts 720p to 1080i/p or Vice Versa
• Standards Conversion: NTSC & PAL I/O
• 3 Gb/s SDI
• 7x SD/HD/3G-SDI Outputs plus Loop Out
• 10-Bit SDI with Low Jitter
• Reference Input & Re-Clocking
• USB & Mini Switches for Configuration
• Network-Controllable via DashBoard

The Blackmagic Design CONVOGCSAUD includes everything you need to de-embed 4 channels of analog audio or 8 channels of AES/EBU digital audio from any SDI video connection. Now you can easily access the audio in any SDI video connection for output to audio equipment such as audio mixers, analog broadcast decks, audio monitors and more!

Blackmagic OpenGear Converters are fully compatible with the OpenGear standard. OpenGear is an open standard for rack mount converters and processing for television broadcasters. OpenGear uses a 2 rack unit rack frame that holds up to 10 plug in cards, or a double density frame can be used to hold up to 20 cards. Many manufacturers develop OpenGear cards and frames that can be mixed and matched. OpenGear cards are hot swappable and can be controlled by java based DashBoard network control and monitoring software on Windows, Mac OS X and Linux.

Product Highlights

• OpenGear Architecture
• Auto SD/HD Switching
• AES/EBU
• USB Upgrade Port
• Powered By Rack

Use the Mini Converter UpDownCross HD from Blackmagic Design to automatically cross-convert between any SD and HD video format, with support for signals up to 1080p60. The converter incorporates one 3G/HD/SD-SDI input, two 3G/HD/SD-SDI outputs and one loop-through output, one HDMI input, and one HDMI output. This versatile converter supports scaling for computer DVI resolutions via its HDMI input, enabling you to connect HDMI computers to SDI projectors.

Features include automatic signal detection, reference in, reclocking, and audio delay for A/V sync. Settings can be easily changed using the diagrammed function switches, or via the OS X/Windows-compatible converter software. This compact converter features a sturdy metal housing, and includes a 12V universal power supply with a locking connection to prevent accidental disconnection.

The Mini Converter SDI Distribution 4K from Blackmagic Design allows you to distribute a Single Link SD/HD/3G/6G-SDI signal to eight SDI devices simultaneously. It automatically detects the input signal type, re-clocks it, and its eight outputs automatically match the SDI input video format. With a compact form factor and easy-to-use controls, the Mini Converter is ideal for a variety of broadcast, post production, and professional AV applications.

Using 6G-SDI technology, the Mini Converter supports resolutions up to Ultra HD 4K (3840 x 2160) at up to 30 fps and DCI 4K (4096 x 2160) at 24 fps, as well as SD, HD, and 3G-SDI signals. It supports all SDI-related transmission features, including embedded audio, ancillary data, and even handles ASI signals – asynchronous signals that carry multiple compressed programs that can be at varying transmission speeds. The Mini Converter’s settings are controlled using the built-in DIP switches or via USB using the included software for Max OS X or Windows computers. The USB port also enables the firmware to be updated. For powering the device, a 12V power supply is included with international socket adapters.

Product Highlights

• De-Embeds Audio from SDI Signal
• Single Link 6G-SDI Input
• Supports SD, HD, UHD 4K & DCI 4K Signals
• Automatic Input Signal Detection
• Redundant SDI Input
• 4x 1/4″ Audio Output Jacks
• 4 Analog or 8 AES/EBU Audio Channels
• 24-Bit, 48 kHz Audio
• Control via DIP Switches or Software
• 12V Universal Power Supply Included

Product Highlights

• Embed Audio into up to 1080p SDI Signals
• Four 1/4″ Audio Input Jacks
• Supports 4 Channels of Analog Audio
• Supports 8 Channels of AES/EBU Audio
• Redundant SDI Backup Input

Product Highlights

• 4K HDMI Input
• 2 x 6G-SDI Outputs
• Supports SD, HD, UHD 4K & DCI 4K Signals
• Automatic Input Signal Detection
• 24-Bit, 48 kHz Audio
• Analog & AES-EBU Digital Audio Inputs
• Embeds Audio Into SDI Output
• Settings via Mini Switches or Software
• USB 2.0 Port for Firmware Updates
• 12V Universal Power Supply Included

The Mini Converter Analog to SDI from Blackmagic will accept an HD/SD component, NTSC, PAL, or S-video signal and convert it to an SDI output. You can also choose to embed SDI audio from balanced AES/EBU or analog audio inputs. Use this device to convert video from Betacam SP, VHS, set-top boxes, HDV cameras, and other similar devices.

Product Highlights

• Analog to SDI Conversion
• Embedded Audio
